Waterproof Stainless Steel Camera

Features:  Firm structure - aluminum-alloy housing, stainless-steel mount and sun-shield  Waterproof and weather resistant housing for outdoor use  Night-vision function (6 infrared lights)  Smaller size for more convenient installation 1/3” SHARP COLOR CCD SENSOR SPECIFICATIONS Image Device: 1/3” SHARP CCD TV System: PAL/NTSC Effective Pixels: 512*582 pixels / 512*492 pixels Sensing Area: 4.9mm*3.7mm Scanning System: 2:1 Interlace Sync. System: Internal Resolution: 420TV Lines Horizontal Sync. Frequency: 15.625KHz / 15.734KHz Vertical Sync. Frequency: 50Hz / 60Hz Minimum Illumination: 0 LUX / F=1.2 (with IR) Microphone: Optional Video Output: 1.0 Vp-p, 75 Ohm Gamma Consumption: 0.45 AGC: Auto S/N Ratio: Better than 48dB White Balance: Auto Electronic Shutter: 1/50 (PAL), 1/60 (NTSC) ~ 1-10,000 Second BLC: Auto Current Consumption: Max. 150 mA Power Supply: DC12V Operation Temperature: -20℃～+70℃, RH 95% Max. Storage Temperature: -40℃～+80℃, RH 95% Max. Lens: f=2.8mm / 3.6mm, F=2.0 Lens Angle: 120°/92°

Firm structure - aluminum-alloy housing, stainless-steel mount and sun-shield Waterproof and weather resistant housing for outdoor use Night-vision function (6 infrared lights)

Features:
 Firm structure - aluminum-alloy housing, stainless-steel mount and sun-shield
 Waterproof and weather resistant housing for outdoor use
 Night-vision function (6 infrared lights)
 Smaller size for more convenient installation

1/3” SHARP COLOR CCD SENSOR SPECIFICATIONS
Image Device: 1/3” SHARP CCD
TV System: PAL/NTSC
Effective Pixels: 512*582 pixels / 512*492 pixels
Sensing Area: 4.9mm*3.7mm
Scanning System: 2:1 Interlace
Sync. System: Internal
Resolution: 420TV Lines
Horizontal Sync. Frequency: 15.625KHz / 15.734KHz
Vertical Sync. Frequency: 50Hz / 60Hz
Minimum Illumination: 0 LUX / F=1.2 (with IR)
Microphone: Optional
Video Output: 1.0 Vp-p, 75 Ohm
Gamma Consumption: 0.45
AGC: Auto
S/N Ratio: Better than 48dB
White Balance: Auto
Electronic Shutter: 1/50 (PAL), 1/60 (NTSC) ~ 1-10,000 Second
BLC: Auto
Current Consumption: Max. 150 mA
Power Supply: DC12V
Operation Temperature: -20℃～+70℃, RH 95% Max.
Storage Temperature: -40℃～+80℃, RH 95% Max.
Lens: f=2.8mm / 3.6mm, F=2.0
Lens Angle: 120°/92°

Sharpvision Co., Ltd. Successfully Initiated the First Winter Sports Meeting

http://www.sharpvision.cn/2011-ydh.htm

At the theme of “Youth as Fire, Beyond Oneself, Eight-year Sharpvision, Keeps Improving”, the first Sharpvision Winter Sports Meeting raised its curtain in Guangdong Polytechnic Nomal University at 8:00am on December 3rd.

Hosted by the management department, this winter sports meeting serves as a good opportunity for all staff to improve our physique and strengthen our will. All stuff divided into four group and over 200 athletes participated in all kind of sports events. The sports meeting was extremely thrilling with reports of victory came in quick succession. All athletes demonstrate their sports expertise, team spirits and civilization as well, definitely playing an exceptional part in our company’s culture construction.

Ather 4 hours fierce competition, the first, second, and third run-ups of all events are competed out:
Female 100-meter sprint: Xu Lingling, Huang Lianzhao, Yang Jingrong.
Male 100-meter sprint: Chen Yibin, He Shengda, Lin Wenxiong.
Female 200-meter sprint: He Chaoxian, Wei Meijuan, Li Haoli.
Male 200-meter sprint: Li Jianzhang, Shu Hao, Huang Jiangfu.
Female 400-meter race: Shan Miandi, Ouyang Hongxia, Huang Meiliu.
Male 400-meter race: Chen Jie, Chen Tingyu, Lin Zhi.
Female 4×100-meter relay: Team Huahua, Team Jilin, Team Chaoxian.
Male 4×100-meter relay: Team Jianming, Team Xiaoshuai, Team Donghai 2.
Female 800-meter race: Huang Jilin, Peng Meng, Liu Xiaoqin.
Male 1500-meter race: Yuan Kun, Li Yonglin, Zhou Ziwen.
Female long jump: Lu Xiaodan, Wei Meijuan, Xu Lingling.
Male long jump: Hu Yong, Wu Guangfeng, Kang Yongyang.
Female standing jump: Lu Xiaodan, Mo Xiaohui, Huang Jilin.
Male standing jump : Chen Jie, Wu Guangfeng, Li De.
Female solid sphere: Xu Lingling, Huang Jilin, Tu Xuelin.
Male solid sphere: He Shengda, Zhang hongyuan, Meng Quanfu.

Athletes are bestowed with medal and awards at the awarding ceremony. General Manager Shi Xinmin declared successful closing at the end of the sports meeting. This sports meeting enriched our life, cultivated staff’s team spirits and improved staff’s quality at large.

Sharpvision's New product----Magnetic base

http://www.sharpvision.cn/accessary/ac539.htm

Sharpvision's New product----Magnetic base

Installation:
 Fix the magnetic base to the U-support bracket of camera and attach the camera to the vehicle.

 Products Compatible:
 CW-073, CW-086, CW-087, CW-639

 Testing Standard:
 The 4.1.2.4 term of ISO16750-3 for vibration test – able to keep still for 8 hours when the value of root mean square
  is 27.8m/s².

We are back from HKTDC HK Electronics Fair 2011 (Autumn)

HKTDC HK Electronics Fair becomes the largest trade fair of electronic products after 30 years of development. The world fair conducted once again in Hong Kong Convention and Exhibition Centre. Sharpvision Co., Ltd., as one of the largest rear view system suppliers, attended this world-class feast again in the manner of an experienced exhibitor.

Sales representatives were sent to the fair. 90% of the buyers are from abroad, which gave a very good opportunity for Sharpvision to promote our products to overseas market. Most of the buyers showed their interest on our monitor series and newly launched products. Our sales members illustrated the products with great patience, leaving a good impression to all customers. Crowded with customers, the booth of Sharpvision performed a great role in promoting and demonstrating our products and our company at large.

Specialized in researching and developing, manufacturing, and sales of rear view system, Sharpvision owns multiple patents, national and international. And Sharpvision had established long-term collaboration tie with numerous world famous enterprises with its 90% products exporting to the USA, Germany, Japan, the UK and other developed countries all around the world.

Sharpvision is to attend the SEMA Show in Las Vegas, Nevada, USA conducted from 1st to 4th November. Our booth number is 11518, and we are looking forward for your visiting.

http://www.sharpvision.cn/2011-hktdc.htm

Sharpvision Successfully Initiated Campus Talk in Guangdong Universities

Sharpvision Co., Ltd. successfully initiated campus talk in Guangdong University of Technology on October 20th, and South China Agriculture University on October 24th, with over 200 students attended respectively. General Manager of Sharpvision Mr. Shi Ximin attended this campus talk despite his busy schedule. Sharpvision, in this campus talk, could recruit more talents of high quality for our future development. Meanwhile, this campus talk facilitated the communication between students and Sharpvision, and further enabled more and more students gain a better knowledge about Sharpvision.

http://www.sharpvision.cn/2011-guanggong.htm

About Sharpvision co.,ltd.



Company Overview
Sharpvision Co., Ltd is a high-tech enterprise engaged in researching, developing, manufacturing and marketing vehicle rear vision products and surveillance products. Founded in 2003, the company is now located in Tianhe district, the economic center of Guangzhou, and run by a strong team of R&D, sales and administration. Ever since it’s foundation, Sharpvision has achieved great success in developing intelligent cameras, high-pixel cameras, digital monitors, wireless receiving systems, image processors , digital video recorders and a series of unique vehicle products, which sets our leading place in vehicle safety industry. With cutting-edge technology and advanced manufacturing facilities, we have become one of the largest suppliers of rear vision products in the world!
The pursuit of quality
Sharpvision emphasizes the advanced enterprise management and regards quality as our lifeline. With thorough quality management system and advanced quality testing equipments, we can conduct various comprehensive performance testing to our products, such as "Low and High Temperature Test" "Vibration Test" "Salt Spray Test" "Swing Test" "Waterproof Test" and "Aging Test" etc… And also we strictly follow the quality control process to grantee the products‘ stability. Sharpvision has been certificated with the highest international level of quality management system in auto industry—ISO/TS16949:2009, and also we are in strict accordance with the EU ROHS standard during manufacturing. Meanwhile, a variety of our products have reached the highest waterproof rating of IP69K, and approved with CE, FCC, EMARK etc. Besides, Sharpvision has also achieved a Utility Model Patent of “Intelligent Controlled Rear View Camera”, and a Design Patent for another three cameras, which bring us a distinguished reputation in the filed of vehicle rear vision products.
Premium service
Premium service is the foundation to win trust from customers, so Sharpvision provides professional OEM and ODM services to meet various needs of customers. And also, with the belief of “Growing with customers” and “Customer oriented”, we dedicate to manufacturing the best products and offering the most satisfying service, even exceeding the expectation of customers to realize mutual benefits.
Excellence and leading
Sharpvision had formed a professional R&D team since its inception. All the way, we have persistently invested new technologies, developed new products, and launched a series of powerful and innovative products to meet the market's demand. In terms of cameras, Sharpvision is the first to launch cameras with super wide viewing angle and night vision. In recent years, we have independently developed a series of friendly-used cameras with attractive appearance, mini size, auto heater, auto shutter etc. These products ensure us a leading position in this industry and good reputation. In terms of monitors, our products are equipped with multiple languages operation, multi-split screen, wide voltage input, automatic backlighting buttons and direct power supply to cameras. More importantly, all of the LCD monitors use digital panel. A variety of monitors have realized touch screen and touch button operation, which are favored by the vast numbers of customers. Our products apply to various kinds of vehicle, such as trucks, buses, ambulances, garbage trucks, fire engines, agricultural vehicles, concrete mixer lorries, excavators, forklifts, road sweepers, cranes and etc. Relying on quality and outstanding styles, Sharpvision products are exported to many developed countries, such as United States, Britain, Germany, Japan and France. We have established long-term mutually beneficial partnership with many world famous enterprises.
Humanity Harmony
Sharpvision adheres to the belief of People-oriented, so we provide competitive salary and welfare, equal opportunities of development, harmonious and comfortable working environment. These give employees a sense of stability, satisfaction, achievement and belonging, which in turn lays a solid foundation for our long-run development. Sharpvision will always stand ready to cooperate with you. Let's grow together!

New staff of Sharpvision gives a tour through South China Botanical Garden

On August 20th, Sharpvision Co., Ltd. orgazised the tenth group of new staff touring to South China Botanical Garden at the aim of visiting and learning.

 http://www.sharpvision.cn/news-peixun10-biye.htm

First Man & Woman Basketball Games at Sharpvision

http://www.sharpvision.cn/2011-basketball-match.htm

Sharpvision`s first man & woman basketball games were hold in Tianhe Jiantao Sports Club at 8:30, 25th, June, 2011. Among the games were Jianmin Team, Xinyu Team, Jilin Team, Xiaole Team, Hongwu Team and Qingxian Team who hold high the slogan of “Like Sport, Like Life, Like Sharpvision.”

During the competition, every player was engaged in the game. Positioning, assist, cut, fast break alike contributed to the exciting games. While the audiences were encouraging, cheering for the players,it seems that they were playing on the court.

In the halftime, with the powerful rhythm, the cheerleaders eased the intense court and cheered up the players to perform more actively, excitedly and wonderfully by the passionate dance.

The games ended up with a great success under the control of our administration department. The Jianmin Team was the winner for the man’s games, while the Xinyu Team was for the woman`s. Moreover, the top scorer were Lao Jianmin(Man) and Li Zhongli(Woman).

The games not only enriched the spare time of our staffs, but more importantly strengthened the sense of doing exercises and cooperation. In addition, relaxed the body and mind, enjoyed the power and warm of the group, and increased the unity of our company and the communication between the departments.

Portable Car Camcorder with 2.0" LTPS TFT LCD DV-378

Portable Car Camcorder with 2.0" LTPS TFT LCD DV-378

Features:
 720P high-definition recording; HDMI output
 5.0Mage pixel of hardware and 12Mage pixel of interpolation
 Support SD card(32 GB)
 Record automatically and repeatedly, needless to worry about memory card
 Automatically record when power on
 Continuously record for more 15s after power off
 120 degree view-angle
 Nigh-vision with infrared LED light
 Lens can be adjusted up-and- down for 30 degree
 Screen can be reversed for 180 degree


Driving recording system with 2.0" LTPS TFT LCD – DV-378
Pixel: 5.0Mage pixel
Lens: 4 prime lens, 7.45mm
Focal length: 12cm to unlimited
Screen: 2.0”LTPS TFT LCD
Output: HDMI, support 720p output
TV system: PAL/NTSC
Image format: JPEG
Max pixel output: 5M，8M，12M
Record format: AVI
Resolution: 1280x720 720P
720x480
680x480
Zoom: 8x digital zoom
Audio: build-in microphone
Memory card: SDHCSD card (max 32G)
Shutter: digital shutter
White balance: auto/sunny/cloudy/tungsten/fluorescent
Port: USB2.0/HDMI/TV
Language: Chinese, English, etc.
Battery: build-in li-ion battery 4V/900mAh
USB: USB2.0 high-speed transmission
Dimension: 98.7(L) x53.3 (W) x23(H) mm
Weight: 90g
Operating temperature: 0-40℃
Accessory: USB/ HDMI/TV data link, in-car charger, lifting rope, mount, instruction book

Car Black Box / Driving recording system with 2.0" LTPS TFT LCD DV-379

http://www.sharpvision.cn/dvr/dv379.htm

 Car Black Box / Driving recording system Features:
 1920 x 1080 high-definition recording
 5.0Mage pixel of hardware and 12Mage pixel of interpolation
 Support mini SD card(32 GB)
 Record automatically and repeatedly, needless to worry about memory card
 Automatically record when power on
 Continuously record for more 15s after power off
 120 degree view-angle
 Nigh-vision with LED fill-in light
 HDMI/TV output
 Screen can be reversed for 270 degree
 Lens can be reversed for 180 degree

Driving recording system with 2.0" LTPS TFT LCD – DV-379
Sensor: CMOS 500Mage pixel
Lens: 4P (1G3P for Mi5120) 1
Focal length: 10cm to unlimited
Zoom: 4x digital zoom
Screen: 2.0”LTPS TFT LCD
Image format: JPEG
Maximum output pixel: 1.3M, 3M, 5M，8M，12M
Video format: MEPG-4AVC/H.264
Resolution:
1080P:1920 x 1080 P30
720P：1280x720 P30 (1280x720 P60--A2S70)
WVGA： 848x480 P 60
QVGA： 320x240 P120
Audio: build-in microphone/speaker
Memory card: 32M for internal, Micro SD card for external (maximum 32G)
Shutter: digital shutter
White balance: auto/sunny/cloudy/tungsten/fluorescent
Port: USB2.0/HDMI/TV
Language: Chinese, English, Russian, etc.
Battery: rechargeable li-ion battery 3.7V 900mAh
Dimension: 96(L) x53(H) x23(H) mm
Weight: 100g
Operating temperature: 0-40℃
Accessory: USB/TV / HDMI data link, in-car charger, mount, instruction book
